Stabilized Crashed Unity Build Server
Context: Unity CI/CD server stability crisis at VARLab (June 2024)
Problem: VM crashes when 2-3 pipelines run simultaneously due to Unity Editor's 100% CPU usage
Solution: Trade-off approach — shared project files + optimization skip
Result: Server stabilized, concurrent pipelines supported
Byproduct: 80% faster builds, 90% CPU reduction
The Crisis
Symptom: CI/CD VM becomes extremely slow or shuts down when 2-3 PR pipelines run simultaneously.
Key Insight: Unity Editor provides no CPU throttling option. It consumes all available resources.
Root Cause Analysis:
| Process | CPU Impact | Build Time |
|---|---|---|
| Unity Editor initial compile (30,000+ files) | 100% | ~10 min |
| wasm-opt.exe (WebAssembly optimization) | 50-100% | 2-3 min |
| IL2CPP.exe (C# to Wasm conversion) | 70-90% | 1-2 sec |
Build time varies by project size and machine resources. CPU always consumes all available resources.
Solution: Trade-off Approach
1. Single Project Files for All Branches
Each branch creates new folder → git clone → Unity initial compile (10 min)
All branches share single project folder → skip initial compile
| Stage | Before | After |
|---|---|---|
| EditMode Test | ~10 min | < 1 min |
| Build Project | ~10 min | 1-5 min |
Validation: Tested with 7 branches — no errors switching between branches.
JIRA Ticket (PDF)2. WebAssembly Optimization Level = 0
wasm-opt.exe runs at 50-100% CPU for 2-3 minutes during CI builds
Set optimization level to 0 for CI pipeline (CD keeps optimization)
| Metric | Before | After |
|---|---|---|
| Peak CPU (wasm-opt.exe) | 50-100% | 0% (skipped) |
| Sustained CPU | 70-90% | 10-20% |
Rationale: CI pipeline only needs to verify build success/failure, not produce optimized artifacts.
Pull Request (PDF) Build Time Reduction Analysis (PDF)Trade-off Accepted
This solution violates CI/CD best practice of "clean builds from scratch":
- Project files and artifacts are retained between builds
- Builds are not fully isolated
Why this was acceptable:
- Unity Editor limitation — no workaround exists
- Modifying Unity Editor internals would violate software compliance
- The trade-off was later resolved with containerization and cloud architecture (see 94.88% Cost Reduction)
Timeline (Git Commits)
| Date | Commit | Description |
|---|---|---|
| Jun 13, 2024 | 33b5daf | Single project files for all branches |
| Jun 19, 2024 | daa5216 | More RAM, less CPU memory setting |
| Jun 24, 2024 | 51d4d74 | Test with enhanced setting (less CPU, more RAM) |
| Jun 24, 2024 | d4c9807 | More memory for il2cpp.exe and wasm-opt.exe |
| Jun 25, 2024 | a35e944 | Original CPU usage setting |
| Jun 25, 2024 | f619a90 | emscripten compiler optimization low setting |
| Jun 26, 2024 | 909d0db | Reduce CPU Usage on CI Pipeline |
